NI M and X Series Terminal Board

The NI M and X Series Terminal Board connects an NI myRIO device to Quanser control plants. It has two analog inputs, two analog outputs, and two single-ended encoder input interfaces. You can access all inputs and outputs simultaneously using unbuffered single-point reads and writes, which is ideal for real-time control. The convenient set of I/O and connectors minimizes setup time and connection errors, so students can concentrate on learning the fundamentals of hardware interfacing and control.
